Benefits & Advantages

FP-IIB-TL-12L flameproof Power LED luminaire is a (certified) flameproof/explosion-proof Power LED luminaire unit, and is designed as a replacement for the conventional 4’ (36W/40W) fluorescent tube light fitting.

• Suitable for Gas Group I IIA/IIB
• Suspended from the ceiling
• Total wattage including that of its inbuilt LED  Driver is 16 watt

  Lighting Up The Future
  TECHNICAL SPECIFICATIONS OF FLAMEPROOF LED FIXTURES
  1. Flameproof cum weatherproof Single fluorescents fitting with IP65 degree of protection. The technical details are as under.
  MATERIAL                  :      Cast Aluminium Alloy LM-6.
  RATING                      :      Single x 40w x 4’
  GLASS                       :       Borosilicate heat and impact resistance clear glass.
  REFLECTOR            :      M.S.Viterous enamelled.
  ENTRY                       :      2Nos. of ¾ ET
  WIREGAURD            :      MS Hot dip galvanized.
  HARDWARE              :     High tensile zinc passivated.
  FINISH                        :     Light grey epoxy shade 631 of IS5.
  STANDARD               :     IS 2148 / 1981 & IS 2147 / 1967.
  CERTIFICATE Approved and certified by CMRS Dhanbad for gas group I, IIA & IIB.
  CAT NO                     :      PS/EXFF/1001-1

  2. Weatherproof Single fluorescents fitting.. The technical details are as under.
  MATERIAL                :       Cast Aluminium Alloy LM-6.
  RATING                    :       Single x 40w x 4’
  GLASS                      :       Clear glass.tube.
  REFLECTOR           :       M.S.Viterous enamelled.
  ENTRY                      :       2Nos. of ¾ ET
  WIREGAURD          :        MS Hot dip galvanized.
  HARDWARE            :        High tensile zinc passivated.
  FINISH                      :        Light grey epoxy shade 631 of IS5.
  CAT NO                    :         PS/FF/1001-1

  3.Flameproof cum weatherproof Integral wellglass fitting with IP65 degree of protection. The technical details are as under.
  MATERIAL                 :       Cast Aluminium Alloy LM-6.
  RATING                     :       Suitable for 55watt LED fittings
  GLASS                       :       Borosilicate toughened type A.
  REFLECTOR            :       M.S.Viterous enamelled.
  ENTRY                       :       2Nos. of ¾ ET
  WIREGAURD            :       MS Hot dip galvanized.
  HARDWARE              :       High tensile zinc passivated.
  FINISH                        :       Light grey epoxy shade 631 of IS5.
  STANDARD               :       IS 2148 / 1981 & IS 2147.
  CERTIFICATE Approved and certified by CMRS Dhanbad for gas group I, IIA & IIB.

  4.Weatherproof Integral wellglass fitting with IP65 degree of protection. The technical details are as under.
  MATERIAL                  :       Cast Aluminium Alloy LM-6.
  RATING                      :       Suitable for 55watt LED fittings
  GLASS                        :       Clear glass.
  REFLECTOR            :        M.S.Viterous enamelled.
  ENTRY                       :         2Nos. of ¾ ET
  WIREGAURD            :        MS Hot dip galvanized.
  HARDWARE              :        High tensile zinc passivated.
  FINISH                        :        Light grey epoxy shade 631 of IS5.
  Ex-Protection             :        Ex “d” Type
  Gas Gr.                       :        I, IIA & IIB
  MOC                            :        Die Cast Aluminium Alloy LM6
  Guard                          :         In M.S. White Power coated
  Zone Classification  :        Zone I and Zone 2
  IP Protection Class  :         IP65
  Finish                          :         Light gray Epoxy Polyester Powder Coating Shade No. 631
  Earthing                      :          Internal 01 No. External 02 nos.
  Cable Entry                :          01 No. for ¾” ET
  “O” Ring                     :          Endless molded neoprene
  Hardware                  :          In Stainless Steel
  Input voltage             :          24VAC, 24VDC or 230VAC (as required)
  Light emission colour :      Cool white


  Ex-Protection: Ex “d” Type
  Gas Gr.: I, IIA & IIB
  MOC: Die Cast Aluminium Alloy LM6
  Guard: In M.S. White Power coated
  Zone Classification: Zone I and Zone 2
  IP Protection Class: IP65
  Finish: Light gray Epoxy Polyester Powder Coating Shade No. 631
  Earthing: Internal 01 No. External 02 nos.
  Cable Entry: 01 No. for ¾” ET
  “O” Ring: Endless molded neoprene
  Hardware: In Stainless Steel
  Input voltage: 24VAC, 24VDC or 230VAC (as required)
  Light emission colour: Cool white
